RayTray is a protective enclosure manufactured with a durable RPVC polymer to ensure a neat and comprehensive routing method for jumper, home run, and equipment-grounding conductor cables.

RayTray is the product of a collaborative effort between solar installers and electrical, structural, and polymer engineers. The result is a wire management system that is simple, durable, cost effective, and ETL listed for use in PV arrays.

Specifications


Product Solar Wire Management System
Material Non-metallic RPVC polymer. UV rating: F1
Listing ETL Intertek conforms to UL Std 870. Voltage rating: 1000 VDC
Installation Flat roofs with pitch < 8 degrees. Standing seam metal roofs
Internal Wiring Maximum of thirty #10 AWG wires/tray. RHW, USE, or PV wire. Maximum wire size: #6 AWG
Grounding Non-metallic RPVC polymer requires no grounding
Material Dimensions Overall height: 2.5", width: 7", length of tray and cap: 8', length of base: 6"
Maximum Support Interval 4'3"
Warranty 15-year warranty against defects in materials and workmanship

logo

• Easy and quick to install
• Low materials cost
• Low labor cost
• Durable and UV resistant
• ETL listed to UL Std 870
• Protects wires from elements
• No roof attachments necessary
• Allows for versatile configurations
• Made in the USA

Installation


Snap and Connect

Cap and Protect

An Easy Change in Direction

Keep Those Home Runs in Line

Protection Enhanced

A Stellar Transition
